ERC721トークンってどうやって表示するんだろう？
ERC721トークンの表示の仕方が気になったのでやってみました。
仕様の確認
以下の仕様を参考にしました。
EIP 721: ERC-721 Non-Fungible Token Standard
openzeppelin ERC721
ざっと見る感じ、tokenURIでトークンプロパティ取得先のURLを取得して、あとは実際にそのURL先を叩くとトークンの情報(JSON)が取得できるみたいです。
それではやっていきたいと思います。
やってみる
環境作り
まず環境を作ります。
node:10.15.3のDockerにtruffleとtruffle unboxのReactをインストールします。
truffle unboxのreactにERC721を表示させていきたいと思います。
$ docker run -it --name erc721_view -p 3000:3000 -v //E/work/erc721_view:/share node:10.15.3 //bin/bash
$ mkdir /share/test
$ cd /share/test
$ npm install truffle
$ npm install nan
$ npx truffle unbox react
あと、取得したtokenURIにリクエストを投げるので、以下もインストールします。
cd client
npm install axios --save
ABIと参照元のコントラクトアドレスを探す
ERC721スマートコントラクトをCallするには、ABIとCall先のアドレスが必要です。
なので、Etherscanから使えそうなものを探してきます。
やはり、有名なMyCryptoHeroes:Heroがいいでしょうか。
https://etherscan.io/token/0x273f7f8e6489682df756151f5525576e322d51a3
参照先のアドレスゲット！
0x273f7f8e6489682df756151f5525576e322d51a3
あとは、abiです。これって自作するしかないのでしょうか？
なかったので、以前OpenSeaのチュートリアルをやった時に作ったERC721のabiを掘り出してきました。
[{"constant":true,"inputs":[{"name":"interfaceId","type":"bytes4"}],"name":"supportsInterface","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x01ffc9a7"},{"constant":true,"inputs":[],"name":"name","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x06fdde03"},{"constant":true,"inputs":[{"name":"tokenId","type":"uint256"}],"name":"getApproved","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x081812fc"},{"constant":false,"inputs":[{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"approve","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x095ea7b3"},{"constant":true,"inputs":[],"name":"totalSupply","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x18160ddd"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"transferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x23b872dd"},{"constant":true,"inputs":[{"name":"owner","type":"address"},{"name":"index","type":"uint256"}],"name":"tokenOfOwnerByIndex","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x2f745c59"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"safeTransferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x42842e0e"},{"constant":true,"inputs":[{"name":"index","type":"uint256"}],"name":"tokenByIndex","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x4f6ccce7"},{"constant":true,"inputs":[{"name":"tokenId","type":"uint256"}],"name":"ownerOf","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x6352211e"},{"constant":true,"inputs":[{"name":"owner","type":"address"}],"name":"balanceOf","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x70a08231"},{"constant":false,"inputs":[],"name":"renounceOwnership","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x715018a6"},{"constant":false,"inputs":[{"name":"_to","type":"address"}],"name":"mintTo","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x755edd17"},{"constant":true,"inputs":[],"name":"owner","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x8da5cb5b"},{"constant":true,"inputs":[],"name":"isOwner","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x8f32d59b"},{"constant":true,"inputs":[],"name":"symbol","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x95d89b41"},{"constant":false,"inputs":[{"name":"to","type":"address"},{"name":"approved","type":"bool"}],"name":"setApprovalForAll","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xa22cb465"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"},{"name":"_data","type":"bytes"}],"name":"safeTransferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xb88d4fde"},{"constant":true,"inputs":[{"name":"_tokenId","type":"uint256"}],"name":"tokenURI","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xc87b56dd"},{"constant":true,"inputs":[{"name":"owner","type":"address"},{"name":"operator","type":"address"}],"name":"isApprovedForAll","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xe985e9c5"},{"constant":false,"inputs":[{"name":"newOwner","type":"address"}],"name":"transferOwnership","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xf2fde38b"},{"inputs":[{"name":"_proxyRegistryAddress","type":"address"}],"payable":false,"stateMutability":"nonpayable","type":"constructor","signature":"constructor"},{"anonymous":false,"inputs":[{"indexed":true,"name":"previousOwner","type":"address"},{"indexed":true,"name":"newOwner","type":"address"}],"name":"OwnershipTransferred","type":"event","signature":"0x8be0079c531659141344cd1fd0a4f28419497f9722a3daafe3b4186f6b6457e0"},{"anonymous":false,"inputs":[{"indexed":true,"name":"from","type":"address"},{"indexed":true,"name":"to","type":"address"},{"indexed":true,"name":"tokenId","type":"uint256"}],"name":"Transfer","type":"event","signature":"0xddf252ad1be2c89b69c2b068fc378daa952ba7f163c4a11628f55a4df523b3ef"},{"anonymous":false,"inputs":[{"indexed":true,"name":"owner","type":"address"},{"indexed":true,"name":"approved","type":"address"},{"indexed":true,"name":"tokenId","type":"uint256"}],"name":"Approval","type":"event","signature":"0x8c5be1e5ebec7d5bd14f71427d1e84f3dd0314c0f7b2291e5b200ac8c7c3b925"},{"anonymous":false,"inputs":[{"indexed":true,"name":"owner","type":"address"},{"indexed":true,"name":"operator","type":"address"},{"indexed":false,"name":"approved","type":"bool"}],"name":"ApprovalForAll","type":"event","signature":"0x17307eab39ab6107e8899845ad3d59bd9653f200f220920489ca2b5937696c31"},{"constant":true,"inputs":[],"name":"baseTokenURI","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xd547cfb7"}]
ソースを改造する
truffe unbox でダウンロードしてきたreactのソースを改造します。
主な変更箇所としては、
- コンストラクトのインスタンス作成部分のabiと参照先のアドレスを変更
- インスタンス作成後にコントラクトからtokenURIを取得、取得したURLから画像情報を取得しstateに設定
- render部分をまるっと変更し取得した画像を並べるように変更
以下、改造したソースです。
/share/test/client/src/App.js
import React, { Component } from 'react';
import getWeb3 from './utils/getWeb3';
import './App.css';
import axios from 'axios';
class App extends Component {
state = { imageList: [] };
componentDidMount = async () => {
try {
const web3 = await getWeb3();
const accounts = await web3.eth.getAccounts();
// abi設定
const abi = [{"constant":true,"inputs":[{"name":"interfaceId","type":"bytes4"}],"name":"supportsInterface","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x01ffc9a7"},{"constant":true,"inputs":[],"name":"name","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x06fdde03"},{"constant":true,"inputs":[{"name":"tokenId","type":"uint256"}],"name":"getApproved","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x081812fc"},{"constant":false,"inputs":[{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"approve","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x095ea7b3"},{"constant":true,"inputs":[],"name":"totalSupply","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x18160ddd"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"transferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x23b872dd"},{"constant":true,"inputs":[{"name":"owner","type":"address"},{"name":"index","type":"uint256"}],"name":"tokenOfOwnerByIndex","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x2f745c59"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"}],"name":"safeTransferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x42842e0e"},{"constant":true,"inputs":[{"name":"index","type":"uint256"}],"name":"tokenByIndex","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x4f6ccce7"},{"constant":true,"inputs":[{"name":"tokenId","type":"uint256"}],"name":"ownerOf","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x6352211e"},{"constant":true,"inputs":[{"name":"owner","type":"address"}],"name":"balanceOf","outputs":[{"name":"","type":"uint256"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x70a08231"},{"constant":false,"inputs":[],"name":"renounceOwnership","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x715018a6"},{"constant":false,"inputs":[{"name":"_to","type":"address"}],"name":"mintTo","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0x755edd17"},{"constant":true,"inputs":[],"name":"owner","outputs":[{"name":"","type":"address"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x8da5cb5b"},{"constant":true,"inputs":[],"name":"isOwner","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x8f32d59b"},{"constant":true,"inputs":[],"name":"symbol","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0x95d89b41"},{"constant":false,"inputs":[{"name":"to","type":"address"},{"name":"approved","type":"bool"}],"name":"setApprovalForAll","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xa22cb465"},{"constant":false,"inputs":[{"name":"from","type":"address"},{"name":"to","type":"address"},{"name":"tokenId","type":"uint256"},{"name":"_data","type":"bytes"}],"name":"safeTransferFrom","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xb88d4fde"},{"constant":true,"inputs":[{"name":"_tokenId","type":"uint256"}],"name":"tokenURI","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xc87b56dd"},{"constant":true,"inputs":[{"name":"owner","type":"address"},{"name":"operator","type":"address"}],"name":"isApprovedForAll","outputs":[{"name":"","type":"bool"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xe985e9c5"},{"constant":false,"inputs":[{"name":"newOwner","type":"address"}],"name":"transferOwnership","outputs":[],"payable":false,"stateMutability":"nonpayable","type":"function","signature":"0xf2fde38b"},{"inputs":[{"name":"_proxyRegistryAddress","type":"address"}],"payable":false,"stateMutability":"nonpayable","type":"constructor","signature":"constructor"},{"anonymous":false,"inputs":[{"indexed":true,"name":"previousOwner","type":"address"},{"indexed":true,"name":"newOwner","type":"address"}],"name":"OwnershipTransferred","type":"event","signature":"0x8be0079c531659141344cd1fd0a4f28419497f9722a3daafe3b4186f6b6457e0"},{"anonymous":false,"inputs":[{"indexed":true,"name":"from","type":"address"},{"indexed":true,"name":"to","type":"address"},{"indexed":true,"name":"tokenId","type":"uint256"}],"name":"Transfer","type":"event","signature":"0xddf252ad1be2c89b69c2b068fc378daa952ba7f163c4a11628f55a4df523b3ef"},{"anonymous":false,"inputs":[{"indexed":true,"name":"owner","type":"address"},{"indexed":true,"name":"approved","type":"address"},{"indexed":true,"name":"tokenId","type":"uint256"}],"name":"Approval","type":"event","signature":"0x8c5be1e5ebec7d5bd14f71427d1e84f3dd0314c0f7b2291e5b200ac8c7c3b925"},{"anonymous":false,"inputs":[{"indexed":true,"name":"owner","type":"address"},{"indexed":true,"name":"operator","type":"address"},{"indexed":false,"name":"approved","type":"bool"}],"name":"ApprovalForAll","type":"event","signature":"0x17307eab39ab6107e8899845ad3d59bd9653f200f220920489ca2b5937696c31"},{"constant":true,"inputs":[],"name":"baseTokenURI","outputs":[{"name":"","type":"string"}],"payable":false,"stateMutability":"view","type":"function","signature":"0xd547cfb7"}];
// アドレスをクリプトヒーローズに変更
const address = '0x273f7f8e6489682df756151f5525576e322d51a3';
const instance = new web3.eth.Contract(abi, address);
this.setState({ web3, accounts, contract: instance });
// 表示したいトークンID設定
const ids = [
'トークンID',
'トークンID',
'トークンID',
];
let dict = [];
let n = 1;
for (var i in ids) {
const response = await this.state.contract.methods
.tokenURI(ids[i])
.call();
axios
.get(response)
.then(res => {
dict.push(
<div
className="item"
style={{ display: 'inline-block' }}
key={n++}
>
<img
src={res['data']['image']}
width="150"
height="150"
border="0"
/>
</div>
);
this.setState({ imageList: dict });
})
.catch(console.error);
}
} catch (error) {
// Catch any errors for any of the above operations.
alert(
`Failed to load web3, accounts, or contract. Check console for details.`
);
console.error(error);
}
};
render() {
if (!this.state.web3) {
return <div>Loading Web3, accounts, and contract...</div>;
}
return <div className="App">{this.state.imageList}</div>;
}
}
export default App;
実際に動かしてみます。
沢山トークンを表示することができました！
※他人のトークンを表示しているので、一応モザイクかけました。
まとめ
15アセット表示するのに大体5秒くらいかかりました。
思っていたより遅かったです...
厳密には、1トークン情報取得～表示までに250ミリ秒ぐらいかかってました。
