#1 「Confluent + RabbitMQ」 で IoTデータを ストリーミング処理してみました

Last updated at Posted at 2021-07-16

STEP-1 : Dockerコンテナ環境での Confluent Platform の構築

概要

Confluent Platform の「cp-all-in-one」 をベースにローカルのDockerコンテナ環境を構築し、IoTデータ生成Pythonプログラムから送信されるデータをRabbitMQで受信し、該当する Source Connector を使用し、Confluent でストリーミング処理をできることを確認しました。

以下の３つのステップで上記内容を順次説明します。今回は STEP-1 について説明します。
STEP-1．Dockerコンテナ環境での Confluent Platform の構築
STEP-2．RabbitMQ経由のBrokerでのデータ受信確認
STEP-3．ストリーミング処理後のデータ受信確認

ローカル環境

macOS Big Sur 11.3
python 3.8.3
Docker version 20.10.7, build f0df350 (CPUs:8, Memory:10GB, Swap:1GB)

Docker を使用した Confluent Platform のダウンロード

  1. confluentinc/cp-all-in-one GitHub リポジトリのクローンを作成します。
  2. 6.0.0-post ブランチをチェックアウトします。
$ cd cp-all-in-one
$ git checkout 6.0.0-post
  1. cp-all-in-one にある cp-all-in-one ディレクトリに移動します。ここが「作業ディレクトリ」となります。
$ cd cp-all-in-one

RabbitMQ Source Connector のインストール

  1. ConfluentのConnectorに「RabbitMQ Source Connector」をインストールするために DockerFileを作業ディレクトリに作成します。
FROM confluentinc/cp-server-connect-base:6.0.0
RUN confluent-hub install --no-prompt confluentinc/kafka-connect-rabbitmq:latest
  1. ConnectorのDockerイメージをビルドします。
$ docker build -t cp-connect-base .

docker-compose.yml の再定義

  1. 作業ディレクトリにある「docker-compose.yml」を以下のように編集します。
サービス名 変更有無 内容
zookeeper 無
broker 無
schema-registry 無
connect 有 使用イメージ変更
control-center 無
ksqldb-server 無
ksqldb-cli 無
ksql-datagen 有 削除
rest-proxy 有 削除
rabbitmq 有 新規追加
docker-compose.yml
version: '2'
services:
  zookeeper:
    image: confluentinc/cp-zookeeper:6.0.0
    hostname: zookeeper
    container_name: zookeeper
    ports:
      - "2181:2181"
    environment:
      ZOOKEEPER_CLIENT_PORT: 2181
      ZOOKEEPER_TICK_TIME: 2000

  broker:
    image: confluentinc/cp-server:6.0.0
    hostname: broker
    container_name: broker
    depends_on:
      - zookeeper
    ports:
      - "9092:9092"
      - "9101:9101"
    environment:
      KAFKA_BROKER_ID: 1
      KAFKA_ZOOKEEPER_CONNECT: 'zookeeper:2181'
      KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: PLAINTEXT:PLAINTEXT,PLAINTEXT_HOST:PLAINTEXT
      KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://broker:29092,PLAINTEXT_HOST://localhost:9092
      KAFKA_METRIC_REPORTERS: io.confluent.metrics.reporter.ConfluentMetricsReporter
      KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
      KAFKA_GROUP_INITIAL_REBALANCE_DELAY_MS: 0
      KAFKA_CONFLUENT_LICENSE_TOPIC_REPLICATION_FACTOR: 1
      KAFKA_CONFLUENT_BALANCER_TOPIC_REPLICATION_FACTOR: 1
      KAFKA_TRANSACTION_STATE_LOG_MIN_ISR: 1
      KAFKA_TRANSACTION_STATE_LOG_REPLICATION_FACTOR: 1
      KAFKA_JMX_PORT: 9101
      KAFKA_JMX_HOSTNAME: localhost
      KAFKA_CONFLUENT_SCHEMA_REGISTRY_URL: http://schema-registry:8081
      CONFLUENT_METRICS_REPORTER_BOOTSTRAP_SERVERS: broker:29092
      CONFLUENT_METRICS_REPORTER_TOPIC_REPLICAS: 1
      CONFLUENT_METRICS_ENABLE: 'true'
      CONFLUENT_SUPPORT_CUSTOMER_ID: 'anonymous'

  schema-registry:
    image: confluentinc/cp-schema-registry:6.0.0
    hostname: schema-registry
    container_name: schema-registry
    depends_on:
      - broker
    ports:
      - "8081:8081"
    environment:
      SCHEMA_REGISTRY_HOST_NAME: schema-registry
      SCHEMA_REGISTRY_KAFKASTORE_BOOTSTRAP_SERVERS: 'broker:29092'
      SCHEMA_REGISTRY_LISTENERS: http://0.0.0.0:8081
      SCHEMA_REGISTRY_ACCESS_CONTROL_ALLOW_ORIGIN: '*'
      SCHEMA_REGISTRY_ACCESS_CONTROL_ALLOW_METHODS: 'GET,POST,PUT,OPTIONS'

  connect:
    image: cp-connect-base:latest
    hostname: connect
    container_name: connect
    depends_on:
      - broker
      - schema-registry
    ports:
      - "8083:8083"
    environment:
      CONNECT_BOOTSTRAP_SERVERS: 'broker:29092'
      CONNECT_REST_ADVERTISED_HOST_NAME: connect
      CONNECT_REST_PORT: 8083
      CONNECT_GROUP_ID: compose-connect-group
      CONNECT_CONFIG_STORAGE_TOPIC: docker-connect-configs
      CONNECT_CONFIG_STORAGE_REPLICATION_FACTOR: 1
      CONNECT_OFFSET_FLUSH_INTERVAL_MS: 10000
      CONNECT_OFFSET_STORAGE_TOPIC: docker-connect-offsets
      CONNECT_OFFSET_STORAGE_REPLICATION_FACTOR: 1
      CONNECT_STATUS_STORAGE_TOPIC: docker-connect-status
      CONNECT_STATUS_STORAGE_REPLICATION_FACTOR: 1
      CONNECT_KEY_CONVERTER: org.apache.kafka.connect.storage.StringConverter
      CONNECT_VALUE_CONVERTER: io.confluent.connect.avro.AvroConverter
      CONNECT_VALUE_CONVERTER_SCHEMA_REGISTRY_URL: http://schema-registry:8081
      CONNECT_INTERNAL_KEY_CONVERTER: "org.apache.kafka.connect.json.JsonConverter"
      CONNECT_INTERNAL_VALUE_CONVERTER: "org.apache.kafka.connect.json.JsonConverter"
      CLASSPATH: /usr/share/java/monitoring-interceptors/monitoring-interceptors-6.0.0.jar
      CONNECT_PRODUCER_INTERCEPTOR_CLASSES: "io.confluent.monitoring.clients.interceptor.MonitoringProducerInterceptor"
      CONNECT_CONSUMER_INTERCEPTOR_CLASSES: "io.confluent.monitoring.clients.interceptor.MonitoringConsumerInterceptor"
      CONNECT_PLUGIN_PATH: "/usr/share/java,/usr/share/confluent-hub-components"
      CONNECT_LOG4J_ROOT_LOGLEVEL: "INFO"
      CONNECT_LOG4J_LOGGERS: org.apache.zookeeper=ERROR,org.I0Itec.zkclient=ERROR,org.org.apache.kafka.connect.runtime.rest=WARN,reflections=ERROR
      CONNECT_HOST: connect

  control-center:
    image: confluentinc/cp-enterprise-control-center:6.0.0
    hostname: control-center
    container_name: control-center
    depends_on:
      - broker
      - schema-registry
      - connect
      - ksqldb-server
    ports:
      - "9021:9021"
    environment:
      CONTROL_CENTER_BOOTSTRAP_SERVERS: 'broker:29092'
      CONTROL_CENTER_CONNECT_CLUSTER: 'connect:8083'
      CONTROL_CENTER_KSQL_KSQLDB1_URL: "http://ksqldb-server:8088"
      CONTROL_CENTER_KSQL_KSQLDB1_ADVERTISED_URL: "http://localhost:8088"
      CONTROL_CENTER_SCHEMA_REGISTRY_URL: "http://schema-registry:8081"
      CONTROL_CENTER_REPLICATION_FACTOR: 1
      CONTROL_CENTER_INTERNAL_TOPICS_PARTITIONS: 1
      CONTROL_CENTER_MONITORING_INTERCEPTOR_TOPIC_PARTITIONS: 1
      CONFLUENT_METRICS_TOPIC_REPLICATION: 1
      PORT: 9021

  ksqldb-server:
    image: confluentinc/cp-ksqldb-server:6.0.0
    hostname: ksqldb-server
    container_name: ksqldb-server
    depends_on:
      - broker
      - connect
    ports:
      - "8088:8088"
    environment:
      KSQL_CONFIG_DIR: "/etc/ksql"
      KSQL_BOOTSTRAP_SERVERS: "broker:29092"
      KSQL_HOST_NAME: ksqldb-server
      KSQL_LISTENERS: "http://0.0.0.0:8088"
      KSQL_CACHE_MAX_BYTES_BUFFERING: 0
      KSQL_KSQL_SCHEMA_REGISTRY_URL: "http://schema-registry:8081"
      KSQL_PRODUCER_INTERCEPTOR_CLASSES: "io.confluent.monitoring.clients.interceptor.MonitoringProducerInterceptor"
      KSQL_CONSUMER_INTERCEPTOR_CLASSES: "io.confluent.monitoring.clients.interceptor.MonitoringConsumerInterceptor"
      KSQL_KSQL_CONNECT_URL: "http://connect:8083"
      KSQL_KSQL_LOGGING_PROCESSING_TOPIC_REPLICATION_FACTOR: 1
      KSQL_KSQL_LOGGING_PROCESSING_TOPIC_AUTO_CREATE: 'true'
      KSQL_KSQL_LOGGING_PROCESSING_STREAM_AUTO_CREATE: 'true'
      KSQL_AUTO_OFFSET_RESET: "latest"

  ksqldb-cli:
    image: confluentinc/cp-ksqldb-cli:6.0.0
    container_name: ksqldb-cli
    depends_on:
      - broker
      - connect
      - ksqldb-server
    entrypoint: /bin/sh
    tty: true

  rabbitmq:
    image: rabbitmq:3.8.17-management
    restart: always
    ports:
      - '5672:5672'
      - '15672:15672'
    hostname: rabbitmq
    container_name: rabbitmq
    environment:
      RABBITMQ_DEFAULT_USER: guest
      RABBITMQ_DEFAULT_PASS: guest

Confluent Platform の起動

  1. -d オプションを使用して Confluent Platform を起動し、デタッチモードで実行します。
$ docker-compose up -d
  1. サービスが稼働状態であることを確認します。
$ docker-compose ps

     Name                    Command               State                               Ports
------------------------------------------------------------------------------------------------------------------------
broker            /etc/confluent/docker/run        Up      0.0.0.0:9092->9092/tcp,:::9092->9092/tcp,
                                                           0.0.0.0:9101->9101/tcp,:::9101->9101/tcp
connect           /etc/confluent/docker/run        Up      0.0.0.0:8083->8083/tcp,:::8083->8083/tcp, 9092/tcp
control-center    /etc/confluent/docker/run        Up      0.0.0.0:9021->9021/tcp,:::9021->9021/tcp
ksql-datagen      bash -c echo Waiting for K ...   Up
ksqldb-cli        /bin/sh                          Up
ksqldb-server     /etc/confluent/docker/run        Up      0.0.0.0:8088->8088/tcp,:::8088->8088/tcp
rabbitmq          docker-entrypoint.sh rabbi ...   Up      15671/tcp, 0.0.0.0:15672->15672/tcp,:::15672->15672/tcp,
                                                           15691/tcp, 15692/tcp, 25672/tcp, 4369/tcp, 5671/tcp,
                                                           0.0.0.0:5672->5672/tcp,:::5672->5672/tcp
rest-proxy        /etc/confluent/docker/run        Up      0.0.0.0:8082->8082/tcp,:::8082->8082/tcp
schema-registry   /etc/confluent/docker/run        Up      0.0.0.0:8081->8081/tcp,:::8081->8081/tcp
zookeeper         /etc/confluent/docker/run        Up      0.0.0.0:2181->2181/tcp,:::2181->2181/tcp, 2888/tcp, 3888/tcp
  1. Connectorも稼働状態であることを確認します。
$ curl http://localhost:8083/connector-plugins | jq

  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100   604  100   604    0     0  10413      0 --:--:-- --:--:-- --:--:-- 10413
[
  {
    "class": "io.confluent.connect.rabbitmq.RabbitMQSourceConnector",
    "type": "source",
    "version": "0.0.0.0"
  },
  {
    "class": "org.apache.kafka.connect.file.FileStreamSinkConnector",
    "type": "sink",
    "version": "6.0.0-ce"
  },
  {
    "class": "org.apache.kafka.connect.file.FileStreamSourceConnector",
    "type": "source",
    "version": "6.0.0-ce"
  },
  {
    "class": "org.apache.kafka.connect.mirror.MirrorCheckpointConnector",
    "type": "source",
    "version": "1"
  },
  {
    "class": "org.apache.kafka.connect.mirror.MirrorHeartbeatConnector",
    "type": "source",
    "version": "1"
  },
  {
    "class": "org.apache.kafka.connect.mirror.MirrorSourceConnector",
    "type": "source",
    "version": "1"
  }
]

これで正常にDockerコンテナ環境下で Confluent Platform の稼働が確認できました。
次のステップでは、IoTデータ生成プログラムからデータを送信し、RabbitMQ経由でBrokerのトピックでデータ受信できることを確認してみます。
