StanとRでベイズ統計モデリング(アヒル本)をPythonにしてみる - 5.3 ロジスティック回帰

実行環境

インポート

import pandas as pd
import numpy as np
from scipy.special import expit
import pystan
from sklearn.metrics import roc_curve
import matplotlib.pyplot as plt
from matplotlib.figure import figaspect
from matplotlib import colors
import seaborn as sns
%matplotlib inline

データ読み込み

attendance3 = pd.read_csv('./data/data-attendance-3.txt')

5.3 ロジスティック回帰

5.3.2 データの分布の確認

pd.crosstab(attendance3['Weather'], attendance3['Y'])

5.3.6 Stanで実装

data = dict(
    I=attendance3.index.size,
    A=attendance3['A'],
    Score=attendance3['Score']/200,
    W=attendance3['Weather'].map(dict(A=0, B=0.2, C=1)),
    Y=attendance3['Y']
)
fit = pystan.stan('./stan/model5-5.stan', data=data, seed=1234)

5.3.7 図によるモデルのチェック

ms = fit.extract()

X = np.arange(30, 201)
q_mcmc = ms['b'][:, 0][:, np.newaxis] + ms['b'][:, 2][:, np.newaxis]*X[np.newaxis, :]/200
q_qua = expit(np.percentile(q_mcmc, (10, 50, 90), axis=0)).T
d_est = pd.DataFrame(np.hstack((X.reshape((-1, 1)), q_qua)), columns=('X', 'p10', 'p50', 'p90'))

plt.figure(figsize=figaspect(3/4.5))
ax = plt.axes()
ax.plot(X, d_est['p50'], c='k')
ax.fill_between(X, d_est['p10'], d_est['p90'], color='k', alpha=2/6)
sns.stripplot('Score', 'Y', data=attendance3.query('A==0 and Weather=="A"'), jitter=True, orient='h', color='k', ax=ax)
plt.setp(ax, xlabel='Score', ylabel='q', ylim=ax.get_ylim()[::-1])
plt.show()

d_qua = pd.DataFrame(np.percentile(ms['q'], (10, 50, 90), axis=0).T, columns=('p10', 'p50', 'p90'))
d_qua = pd.concat([attendance3, d_qua], axis=1)

plt.figure(figsize=figaspect(3/4.5))
ax = plt.axes()
ax.violinplot([d_qua.query('Y==@i')['p50'].values for i in range(2)], positions=[0, 1], vert=False)
sns.stripplot('p50', 'Y', hue='A', data=d_qua, jitter=True, orient='h', palette={0: colors.to_rgb('black'), 1: colors.to_rgb('gray')}, size=3, ax=ax)
plt.setp(ax, xlabel='q', ylabel='Y', yticks=(0, 1), ylim=ax.get_ylim()[::-1])
plt.show()

ms = fit.extract()

N_mcmc = ms['lp__'].size
spec = np.linspace(0, 1, 201)
probs = [10, 50, 90]

def roc(i):
    fpr, tpr, _ = roc_curve(attendance3['Y'], ms['q'][i, :], drop_intermediate=False)
    return np.interp(spec, fpr, tpr)

m_roc = np.array(list(map(roc, range(N_mcmc))))
d_est = pd.DataFrame(np.hstack((spec.reshape(-1, 1), np.percentile(m_roc, probs, axis=0).T)), columns=['X'] + ['p{}'.format(p) for p in probs])

ax = d_est.plot('X', 'p50', figsize=figaspect(1), legend=False, c='k')
ax.fill_between('X', 'p10', 'p90', data=d_est, color='k', alpha=2/6)
lim = ax.get_xlim()
ax.plot(lim, lim, c='k', alpha=0.5)
plt.setp(ax, xlim=lim, ylim=lim, xlabel='False Positive', ylabel='True Positive')
plt.show()
