#初めに
DevNet Sandboxを使って簡単にpyATS/Genieを試すことができる非常に良い記事があるので、その記事を参考にしながらGenieのParsersを試してみました。
（参考記事）
- DevNet Sandboxを使ってpyATS/XPRESSOをCML2と始めよう
#Genieとは
Genieとは、pyATSフレームワークのモジュラーアーキテクチャにバンドルされているネットワークテスト自動化に必要なすべてのツールを含むpyATS用のPythonライブラリ。
#デバイスアウトプットの構造化
GenieのParsersを使用すると、showコマンドを構造化（Json / Dictionary）して出力することができます。
#testbed.yamlファイル
DevNet Sandboxの「Cisco pyATS XPRESSO」の環境でデモを実行します。
GenieのParsers、Models、Apisなどの各ライブラリを使用するためには、testbedというネットワーク構成を記載したyamlファイルが必要です。参考記事にもあるようにSandbox内にtestbed.yamlは準備されてますが、デバイスへのアクセスをterminal_server経由ではなく直接アドレスでアクセスするように、また、seriesをplatform表記へと修正しました。サポートされるPlatformsはこちらで確認できます。
testbed.yaml
testbed:
name: 'Multi Platform Network'
credentials:
default:
username: cisco
password: cisco
devices:
internet-rtr01:
os: iosxe
platform: csr1000v
alias: uut
type: router
connections:
defaults:
via: cli
cli:
ip: 10.10.20.181
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
internet-host01:
os: linux
alias: ub01
type: server
connections:
defaults:
via: cli
cli:
ip: 10.10.20.182
protocol: ssh
credentials:
default:
username: cisco
password: cisco
edge-firewall01:
os: asa
platform: asav
alias: asa
type: firewall
connections:
defaults:
via: cli
cli:
ip: 10.10.20.171
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
core-rtr01:
os: iosxr
platform: iosxrv
alias: xr01
type: router
connections:
defaults:
via: cli
cli:
ip: 10.10.20.173
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
core-rtr02:
os: iosxr
platform: iosxrv
alias: xr02
type: router
connections:
defaults:
via: cli
cli:
ip: 10.10.20.174
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
dist-rtr01:
os: iosxe
platform: csr1000v
alias: xe01
type: router
connections:
defaults:
via: cli
cli:
ip: 10.10.20.175
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
dist-rtr02:
os: iosxe
platform: csr1000v
alias: xe02
type: router
connections:
defaults:
via: cli
cli:
ip: 10.10.20.176
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
dist-sw01:
os: nxos
platform: n9k
alias: nx01
type: switch
connections:
defaults:
via: cli
cli:
ip: 10.10.20.177
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
dist-sw02:
os: nxos
platform: n9k
alias: nx02
type: switch
connections:
defaults:
via: cli
cli:
ip: 10.10.20.178
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
inside-host01:
os: linux
alias: ub02
type: server
connections:
defaults:
via: cli
cli:
ip: 10.10.20.179
protocol: ssh
credentials:
default:
username: cisco
password: cisco
edge-sw01:
os: ios
platform: iosv
alias: sw
type: switch
connections:
defaults:
via: cli
cli:
ip: 10.10.20.172
protocol: telnet
port: 23
credentials:
default:
username: cisco
password: cisco
enable:
password: cisco
inside-host02:
os: linux
alias: desktop
type: server
connections:
defaults:
via: cli
cli:
ip: 10.10.20.180
protocol: ssh
credentials:
default:
username: cisco
password: cisco
topology:
internet-rtr01:
interfaces:
Loopback0:
type: loopback
GigabitEthernet1:
link: l20
type: ethernet
GigabitEthernet2:
link: l1
type: ethernet
GigabitEthernet3:
link: l0
type: ethernet
GigabitEthernet4:
type: ethernet
internet-host01:
interfaces:
ens3:
link: l0
type: ethernet
enp4:
type: ethernet
ens5:
type: ethernet
ens6:
type: ethernet
ens7:
type: ethernet
ens8:
type: ethernet
ens9:
link: l29
type: ethernet
edge-firewall01:
interfaces:
Management0/0:
link: l21
type: ethernet
GigabitEthernet0/0:
link: l1
type: ethernet
GigabitEthernet0/1:
link: l2
type: ethernet
core-rtr01:
interfaces:
Loopback0:
type: loopback
MgmtEth0/0/CPU0/0:
link: l23
type: ethernet
GigabitEthernet0/0/0/0:
link: l3
type: ethernet
GigabitEthernet0/0/0/1:
link: l7
type: ethernet
GigabitEthernet0/0/0/2:
link: l9
type: ethernet
GigabitEthernet0/0/0/3:
link: l10
type: ethernet
core-rtr02:
interfaces:
Loopback0:
type: loopback
MgmtEth0/0/CPU0/0:
link: l24
type: ethernet
GigabitEthernet0/0/0/0:
link: l3
type: ethernet
GigabitEthernet0/0/0/1:
link: l8
type: ethernet
GigabitEthernet0/0/0/2:
link: l11
type: ethernet
GigabitEthernet0/0/0/3:
link: l12
type: ethernet
dist-rtr01:
interfaces:
Loopback0:
type: loopback
GigabitEthernet1:
link: l4
type: ethernet
GigabitEthernet2:
link: l9
type: ethernet
GigabitEthernet3:
link: l11
type: ethernet
GigabitEthernet4:
link: l13
type: ethernet
GigabitEthernet5:
link: l14
type: ethernet
GigabitEthernet6:
link: l26
type: ethernet
dist-rtr02:
interfaces:
Loopback0:
type: loopback
GigabitEthernet1:
link: l25
type: ethernet
GigabitEthernet2:
link: l10
type: ethernet
GigabitEthernet3:
link: l12
type: ethernet
GigabitEthernet4:
link: l15
type: ethernet
GigabitEthernet5:
link: l16
type: ethernet
GigabitEthernet6:
link: l26
type: ethernet
dist-sw01:
interfaces:
Loopback0:
type: loopback
mgmt0:
link: l27
type: ethernet
Ethernet1/1:
link: l5
type: ethernet
Ethernet1/2:
link: l6
type: ethernet
Ethernet1/3:
link: l13
type: ethernet
Ethernet1/4:
link: l15
type: ethernet
Ethernet1/5:
type: ethernet
Ethernet1/6:
type: ethernet
Ethernet1/7:
type: ethernet
Ethernet1/8:
type: ethernet
Ethernet1/9:
type: ethernet
Ethernet1/10:
type: ethernet
Ethernet1/11:
link: l17
type: ethernet
dist-sw02:
interfaces:
Loopback0:
type: loopback
mgmt0:
link: l28
type: ethernet
Ethernet1/1:
link: l5
type: ethernet
Ethernet1/2:
link: l6
type: ethernet
Ethernet1/3:
link: l14
type: ethernet
Ethernet1/4:
link: l16
type: ethernet
Ethernet1/5:
type: ethernet
Ethernet1/6:
type: ethernet
Ethernet1/7:
type: ethernet
Ethernet1/8:
type: ethernet
Ethernet1/9:
type: ethernet
Ethernet1/10:
type: ethernet
Ethernet1/11:
link: l18
type: ethernet
inside-host01:
interfaces:
ens3:
link: l17
type: ethernet
ens4:
type: ethernet
ens5:
type: ethernet
ens6:
type: ethernet
ens7:
type: ethernet
ens8:
type: ethernet
enp9:
link: l30
type: ethernet
edge-sw01:
interfaces:
Loopback0:
type: loopback
GigabitEthernet0/0:
link: l22
type: ethernet
GigabitEthernet0/1:
link: l2
type: ethernet
GigabitEthernet0/2:
link: l7
type: ethernet
GigabitEthernet0/3:
link: l8
type: ethernet
inside-host02:
interfaces:
eth0:
link: l18
type: ethernet
eth1:
link: l31
type: ethernet
testbed.yamlはpyats validate testbedで構造に誤りがないか確認することができ、--connectオプションを付けることで同時にデバイスへの接続テストも実行することができます。
(py3venv) [developer@devbox ~]$ pyats validate testbed --connect testbed.yaml
Loading testbed file: testbed.yaml
--------------------------------------------------------------------------------
Testbed Name:
Multi Platform Network
Testbed Devices:
.
|-- core-rtr01 [router/iosxr/iosxrv]
| |-- GigabitEthernet0/0/0/0 ----------> l3
| |-- GigabitEthernet0/0/0/1 ----------> l7
| |-- GigabitEthernet0/0/0/2 ----------> l9
| |-- GigabitEthernet0/0/0/3 ----------> l10
| |-- Loopback0
| `-- MgmtEth0/0/CPU0/0 ----------> l23
|-- core-rtr02 [router/iosxr/iosxrv]
| |-- GigabitEthernet0/0/0/0 ----------> l3
| |-- GigabitEthernet0/0/0/1 ----------> l8
| |-- GigabitEthernet0/0/0/2 ----------> l11
| |-- GigabitEthernet0/0/0/3 ----------> l12
| |-- Loopback0
| `-- MgmtEth0/0/CPU0/0 ----------> l24
|-- dist-rtr01 [router/iosxe/csr1000v]
| |-- GigabitEthernet1 ----------> l4
| |-- GigabitEthernet2 ----------> l9
| |-- GigabitEthernet3 ----------> l11
| |-- GigabitEthernet4 ----------> l13
| |-- GigabitEthernet5 ----------> l14
| |-- GigabitEthernet6 ----------> l26
| `-- Loopback0
|-- dist-rtr02 [router/iosxe/csr1000v]
| |-- GigabitEthernet1 ----------> l25
| |-- GigabitEthernet2 ----------> l10
| |-- GigabitEthernet3 ----------> l12
| |-- GigabitEthernet4 ----------> l15
| |-- GigabitEthernet5 ----------> l16
| |-- GigabitEthernet6 ----------> l26
| `-- Loopback0
|-- dist-sw01 [switch/nxos/n9k]
| |-- Ethernet1/1 ----------> l5
| |-- Ethernet1/10
| |-- Ethernet1/11 ----------> l17
| |-- Ethernet1/2 ----------> l6
| |-- Ethernet1/3 ----------> l13
| |-- Ethernet1/4 ----------> l15
| |-- Ethernet1/5
| |-- Ethernet1/6
| |-- Ethernet1/7
| |-- Ethernet1/8
| |-- Ethernet1/9
| |-- Loopback0
| `-- mgmt0 ----------> l27
|-- dist-sw02 [switch/nxos/n9k]
| |-- Ethernet1/1 ----------> l5
| |-- Ethernet1/10
| |-- Ethernet1/11 ----------> l18
| |-- Ethernet1/2 ----------> l6
| |-- Ethernet1/3 ----------> l14
| |-- Ethernet1/4 ----------> l16
| |-- Ethernet1/5
| |-- Ethernet1/6
| |-- Ethernet1/7
| |-- Ethernet1/8
| |-- Ethernet1/9
| |-- Loopback0
| `-- mgmt0 ----------> l28
|-- edge-firewall01 [firewall/asa/asav]
| |-- GigabitEthernet0/0 ----------> l1
| |-- GigabitEthernet0/1 ----------> l2
| `-- Management0/0 ----------> l21
|-- edge-sw01 [switch/ios/iosv]
| |-- GigabitEthernet0/0 ----------> l22
| |-- GigabitEthernet0/1 ----------> l2
| |-- GigabitEthernet0/2 ----------> l7
| |-- GigabitEthernet0/3 ----------> l8
| `-- Loopback0
|-- inside-host01 [server/linux]
| |-- enp9 ----------> l30
| |-- ens3 ----------> l17
| |-- ens4
| |-- ens5
| |-- ens6
| |-- ens7
| `-- ens8
|-- inside-host02 [server/linux]
| |-- eth0 ----------> l18
| `-- eth1 ----------> l31
|-- internet-host01 [server/linux]
| |-- enp4
| |-- ens3 ----------> l0
| |-- ens5
| |-- ens6
| |-- ens7
| |-- ens8
| `-- ens9 ----------> l29
`-- internet-rtr01 [router/iosxe/csr1000v]
|-- GigabitEthernet1 ----------> l20
|-- GigabitEthernet2 ----------> l1
|-- GigabitEthernet3 ----------> l0
|-- GigabitEthernet4
`-- Loopback0
YAML Lint Messages
------------------
Connection Check
----------------
note that connection checks are not 100% accurate - it does not take
into account that connection implementations may choose to interpret
the entire connection block differently.
For example - Unicon autouses A/B console/standby, but does not allow
explicit connection to B.
- internet-rtr01/cli [PASSED]
- internet-host01/cli [PASSED]
- edge-firewall01/cli [PASSED]
- core-rtr01/cli [PASSED]
- core-rtr02/cli [PASSED]
- dist-rtr01/cli [PASSED]
- dist-rtr02/cli [PASSED]
- dist-sw01/cli [PASSED]
- dist-sw02/cli [PASSED]
- inside-host01/cli [PASSED]
- edge-sw01/cli [PASSED]
- inside-host02/cli [PASSED]
Warning Messages
----------------
- Device 'inside-host01' missing 'platform' definition
- Device 'inside-host02' missing 'platform' definition
- Device 'internet-host01' missing 'platform' definition
(py3venv) [developer@devbox ~]$
#pythonでの 'show version'の構造化
CML2内の「internet-rtr01」で show versionをpythonでparseしてみます。
(py3venv) [developer@devbox ~]$ python
Python 3.6.8 (default, Sep 14 2019, 14:33:46)
[GCC 4.8.5 20150623 (Red Hat 4.8.5-36)] on linux
Type "help", "copyright", "credits" or "license" for more information.
>>> from genie import testbed
>>> testbed = testbed.load('testbed.yaml')
>>> router_xe = testbed.devices['uut']
>>> router_xe.connect()
2021-08-26 15:47:09,290: %UNICON-INFO: +++ internet-rtr01 logfile /tmp/internet-rtr01-cli-20210826T154709289.log +++
2021-08-26 15:47:09,290: %UNICON-INFO: +++ Unicon plugin iosxe +++
Trying 10.10.20.181...
2021-08-26 15:47:09,317: %UNICON-INFO: +++ connection to spawn: telnet 10.10.20.181 23, id: 140486312744888 +++
2021-08-26 15:47:09,318: %UNICON-INFO: connection to internet-rtr01
Connected to 10.10.20.181.
Escape character is '^]'.
User Access Verification
Username: cisco
Password:
internet-rtr01#
2021-08-26 15:47:10,584: %UNICON-INFO: +++ initializing handle +++
2021-08-26 15:47:10,585: %UNICON-INFO: +++ internet-rtr01: executing command 'term length 0' +++
term length 0
internet-rtr01#
2021-08-26 15:47:10,747: %UNICON-INFO: +++ internet-rtr01: executing command 'term width 0' +++
term width 0
internet-rtr01#
2021-08-26 15:47:10,885: %UNICON-INFO: +++ internet-rtr01: executing command 'show version' +++
show version
Cisco IOS XE Software, Version 16.11.01b
Cisco IOS Software [Gibraltar], Virtual XE Software (X86_64_LINUX_IOSD-UNIVERSALK9-M), Version 16.11.1b, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2019 by Cisco Systems, Inc.
Compiled Tue 28-May-19 12:45 by mcpre
Cisco IOS-XE software, Copyright (c) 2005-2019 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMON
internet-rtr01 uptime is 13 minutes
Uptime for this control processor is 14 minutes
System returned to ROM by reload
System image file is "bootflash:packages.conf"
Last reload reason: Unknown reason
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you require further assistance please contact us by sending email to
export@cisco.com.
License Level: ax
License Type: N/A(Smart License Enabled)
Next reload license Level: ax
Smart Licensing Status: UNREGISTERED/No Licenses in Use
cisco CSR1000V (VXE) processor (revision VXE) with 2167316K/3075K bytes of memory.
Processor board ID 9CR4CCWS6O2
4 Gigabit Ethernet interfaces
32768K bytes of non-volatile configuration memory.
3984308K bytes of physical memory.
16162815K bytes of virtual hard disk at bootflash:.
0K bytes of WebUI ODM Files at webui:.
Configuration register is 0x2102
internet-rtr01#
2021-08-26 15:47:11,032: %UNICON-INFO: +++ internet-rtr01: configure +++
config term
Enter configuration commands, one per line. End with CNTL/Z.
internet-rtr01(config)#no logging console
internet-rtr01(config)#line console 0
internet-rtr01(config-line)#exec-timeout 0
internet-rtr01(config-line)#end
internet-rtr01#
>>>
>>>
>>> output = router_xe.parse("show version")
2021-08-26 15:47:23,679: %UNICON-INFO: +++ internet-rtr01: executing command 'show version' +++
show version
Cisco IOS XE Software, Version 16.11.01b
Cisco IOS Software [Gibraltar], Virtual XE Software (X86_64_LINUX_IOSD-UNIVERSALK9-M), Version 16.11.1b, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2019 by Cisco Systems, Inc.
Compiled Tue 28-May-19 12:45 by mcpre
Cisco IOS-XE software, Copyright (c) 2005-2019 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMON
internet-rtr01 uptime is 13 minutes
Uptime for this control processor is 14 minutes
System returned to ROM by reload
System image file is "bootflash:packages.conf"
Last reload reason: Unknown reason
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you require further assistance please contact us by sending email to
export@cisco.com.
License Level: ax
License Type: N/A(Smart License Enabled)
Next reload license Level: ax
Smart Licensing Status: UNREGISTERED/No Licenses in Use
cisco CSR1000V (VXE) processor (revision VXE) with 2167316K/3075K bytes of memory.
Processor board ID 9CR4CCWS6O2
4 Gigabit Ethernet interfaces
32768K bytes of non-volatile configuration memory.
3984308K bytes of physical memory.
16162815K bytes of virtual hard disk at bootflash:.
0K bytes of WebUI ODM Files at webui:.
Configuration register is 0x2102
internet-rtr01#
>>>
>>>
>>> import pprint
>>> pprint.pprint(output)
{'version': {'chassis': 'CSR1000V',
'chassis_sn': '9CR4CCWS6O2',
'compiled_by': 'mcpre',
'compiled_date': 'Tue 28-May-19 12:45',
'curr_config_register': '0x2102',
'disks': {'bootflash:.': {'disk_size': '16162815',
'type_of_disk': 'virtual hard disk'},
'webui:.': {'disk_size': '0',
'type_of_disk': 'WebUI ODM Files'}},
'hostname': 'internet-rtr01',
'image_id': 'X86_64_LINUX_IOSD-UNIVERSALK9-M',
'image_type': 'production image',
'last_reload_reason': 'Unknown reason',
'license_level': 'ax',
'license_type': 'N/A(Smart License Enabled)',
'main_mem': '2167316',
'mem_size': {'non-volatile configuration': '32768',
'physical': '3984308'},
'next_reload_license_level': 'ax',
'number_of_intfs': {'Gigabit Ethernet': '4'},
'os': 'IOS-XE',
'platform': 'Virtual XE',
'processor_type': 'VXE',
'returned_to_rom_by': 'reload',
'rom': 'IOS-XE ROMMON',
'rtr_type': 'CSR1000V',
'system_image': 'bootflash:packages.conf',
'uptime': '13 minutes',
'uptime_this_cp': '14 minutes',
'version': '16.11.1b',
'version_short': '16.11'}}
>>>
show versionのアウトプットが辞書型に構造化されました。
このようにデバイスアウトプットが構造化されることで、人の目には認識しにくくなりますが、プログラミング時に欲しい情報を簡単に取り出すことができ扱いやすくなります。
なお、OS毎にサポートされているParsersはこちらです。
#参考リンク
- DevNet Sandboxを使ってpyATS/XPRESSOをCML2と始めよう
- Genie Documentation
- Unicon: The Connection Library
- genie-feature-browser
