Processingで障子に穴を開ける

小さい頃、障子に穴を開けて怒られてしまったことはありませんか？

Processingを使って、障子に穴を開けましょう。もう二度と怒られることはありません。

（用意するもの）
・障子
・プロジェクター
・テンキー
・プログラム（下に記載しています）

こんな感じです↓

Processing with "Shoji"#Processing #shoji #障子 #interactive #mediaart pic.twitter.com/Q0E9kuhuqB

— kdmyk (@kd_myk) January 31, 2020

指のアニメーションは、2000 x 500 pix のキャンバスに 250 x250 pix のコマを貼っています。
Processingでは、この一つのキャンバスの左上から順に画像を切り出し、表示すると云う処理を行います。

こちらがコードです↓

class shojiScene{

  //devide image
  ArrayList<PImage>  shojiFrame = new ArrayList<PImage>();
  int yubiframe = 0;

  shojiScene( int mx, int my, int fx, int fy, String image ){

    PImage  yubi;
    yubi = loadImage( image );

    for( int ycount = 0; ycount < fy; ycount++ ){
      for( int xcount = 0; xcount < fx; xcount++ ){

        PImage  work1;
        int x = xcount * mx;
        int y = ycount * my;
        work1 = yubi.get( x, y, mx, my );
        shojiFrame.add( work1 );
      }
    }
  }

  //pick up from the top
  boolean disp( int x, int y ){

    PImage work2;
    work2 = shojiFrame.get( yubiframe );
    image( work2, x, y );
    yubiframe++;

    boolean  ret = false;
    if( yubiframe > shojiFrame.size() - 1 ){
      yubiframe = 0;
      ret = true;
    }
    return( ret );
  }
}



class anime {
  class sceneMng {
    shojiScene   ds;  //scene
    int        dx;  //point of x axis
    int        dy;  //point of y axis

    sceneMng( shojiScene s, int x, int y ){
      ds = s;
      dx = x;
      dy = y;
    }
  }

  //manage for different scenes
  ArrayList<sceneMng>  sceneList;

  anime(){
    sceneList = new ArrayList<sceneMng>();
  }

  //add scene
  //sn : adding scene  x / y : locate of display
  void addScene( shojiScene sn, int x, int y ){
    sceneMng sm = new sceneMng( sn, x, y );
    sceneList.add( sm );
  }

  void disp(){
    boolean dispEnd = false;

    //pick up all scenes from top and show it in order
    for( int index = 0; index < sceneList.size(); index++ ){
      sceneMng  dispSheen = sceneList.get( index );
      dispEnd = dispSheen.ds.disp( dispSheen.dx, dispSheen.dy );
      if( dispEnd == true ){

        sceneList.remove( index );
      }
    }
  }
}



anime      animeList;
shojiScene   Shoji;

final float TARGET_FPS = 12.0f;                // frame rate
final float FRAME_TIME = 1000.0f / TARGET_FPS; // processing time of one frame
int lastUpdateTime = 0;                        // update time
float passageTime = 0.0f;                      // passage time orom previors frame


void setup(){
  size( 1300,768 );
  animeList = new anime();

  frameRate( TARGET_FPS );
}

void draw(){
  background( 255 );
  fill(0);


  //sikaku
  rect(0,0,670,90);//rahmen
  rect(670,0,1300,80);//rahmen
  rect(0,760,760,10);//rahmen
  rect(670,760,1300,20);//rahmen
  rect(0,0,195,780);//rahmen
  rect(1175,0,1130,800);//rahmen

  rect(435,80,240,230);
  rect(940,305,240,225);
  rect(195,535,240,230);
  rect(680,530,255,230);

  //measure from last time and this time
  int curTime = millis();     //current time
  passageTime += curTime - lastUpdateTime; //passage time
  lastUpdateTime = curTime;   // update time

  //display the time of late frames
  for( ; passageTime >= FRAME_TIME; passageTime -= FRAME_TIME) {
    animeList.disp();
  }


  }


void keyPressed(){

    if( key == '1' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 940,540 );
      }
    if( key == '3' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 440,540 );
      }
    if( key == '5' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 690,310 );
      }
    if( key == '6' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 440,310 );
      }
    if( key == '7' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 940,80 );
      }
    if( key == '8' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 690,80 );
      }
    if( key == '+' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 200,310 );
      }
    if( key == '-' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 200,80 );
      }
    if( key == '/' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 960,0 );
          }
    if( key == '*' ){
    Shoji = new shojiScene( 250, 250, 8, 2, "yubi_2.png" );
    animeList.addScene( Shoji, 690,0 );

  }

else {

  }
  }
```

ぜひお試しを！
